MCCB Triple Pole Incoming NZM2 Frame 250A 36kA
£416.22
Part Number: 2500461604 MPN: 166425 Product Type: Moulded Case Circuit Breakers
Description
Part Number: 2500461604 MPN: 166425 Product Type: Moulded Case Circuit Breakers
Product Details
Eaton Memshield 3 Incoming Moulded Case Circuit Breaker is certified to IEC60947-2 standards. The MCCB panel board providing all the options you need from a straight forward panel board to a comprehensive panel board system. The range now offers a variety
- Providing safety, reliability and performance in commercial, industrial applications
- Maximum cable capacity 185mm²
- Adjustable trip
- Thermal trip adjustment 0.8 to 1 x In, magnetic trip adjustment 6 to 10 x In
Technical Specifications
Moulded case circuit breaker (MCCB) |
|
| Rated voltage | 690 – 690 V |
|---|---|
| Complete device with protection unit | Yes |
| DIN rail (top hat rail) mounting optional | Yes |
| Motor drive optional | Yes |
| Suitable for DIN rail (top hat rail) mounting | No |
| Integrated earth fault protection | No |
| Switched-off indicator available | No |
| Motor drive integrated | No |
| With integrated under voltage release | No |
| Adjustment range undelayed short-circuit release | 0 – 0 A |
| Adjustment range short-term delayed short-circuit release | 0 – 0 A |
| Position of connection for main current circuit | Front |
|---|---|
| Overload release current setting | 200 – 250 A |
| Rated short-circuit breaking capacity Icu at 400 V, 50 Hz | 36 kA |
| Number of auxiliary contacts as change-over contact | 0 |
| Number of poles | 3 |
| Rated permanent current Iu | 250 A |
| Number of auxiliary contacts as normally closed contact | 0 |
| Number of auxiliary contacts as normally open contact | 0 |
| Type of control element | Rocker lever |
| Device construction | Built-in device fixed built-in technique |
| Degree of protection (IP rating) | IP20 |
