40A 30mA SPswN C Curve 6kA Type A Miniature RCBO

£89.32

Part Number: 2501074755    MPN: 61/CM4030     Product Type: Residual Current Devices

Category:

Description

Part Number: 2501074755    MPN: 61/CM4030     Product Type: Residual Current Devices

Product Details

Crabtree Starbreaker Miniature RCBO is a plug-in MCB sized, for use in domestic household premises and similar installations. Starbreaker miniature RCBO brings higher levels of safety to an electrical installation and its users because it includes switche

  • Single module, Miniature RCBO
  • 40A C curve (MCB), 30mA Type A (RCD)
  • Single pole with switched neutral
  • Plug in
  • RCD Type A – Pure AC and pulsating DC sensitivity
  • BS 7671 IET Wiring Regulations
  • Switched neutral built in as standard, fully isolates faults
  • Instant guaranteed plug in connections
  • Fully insulated busbar with permanent shields
  • Neutral conductor switching

Technical Specifications

Earth leakage circuit breaker/RCBO
Rated fault current 0.03 A
Flush-mounted installation No
Anti-nuisance tripping version No
Concurrently switching N-neutral Yes
With interlocking device No
Connectable conductor cross section solid-core 0.75 – 16 mm²
Ambient temperature during operating -5 – 40 °C
Connectable conductor cross section multi-wired 0.75 – 16 mm²
Recess depth 73 mm
Number of protected poles 1
Over voltage category 3
Rated short-circuit breaking capacity Icn according to EN 61009-1 6 kA
Rated impulse-withstand voltage (Uimp) 4 kV



Tripping characteristic (type/curve) C
Rated current 40 A
Width in number of modular spacings 1
Number of poles (total) 2
Current limiting class 3
Rated insulation voltage Ui 400 V
Rated voltage 230 V
Voltage type AC
Degree of protection (IP rating) IP20
Frequency 50 Hz
Disconnection characteristic Undelayed
Leakage current type A
