Distribution Board 16Way Single Pole+Neutral 125A
£318.51
Part Number: 2500329250 MPN: EAM16 Product Type: Distribution Boards Single Phase
Description
Part Number: 2500329250 MPN: EAM16 Product Type: Distribution Boards Single Phase
Product Details
MEM A distribution board; 16-way SPN
- Interlinking form for improved positional security
- Removable main busbar for flexible installation
- Unique full form blanking modules for unused MCB ways. Provides secure shrouding of unused busbar st
- Main busbar is removable for flexible installation.
- Fully shrouded Neutral busbar for increased safety
- Choice of metering option to suit application needs and aid compliance with latest Building Regulati
- Door opens 180 to provide easy access and device operation
- Standard incomer Switch Disconnector rating of 125A provides higher rated solution for commercial bu
- 125A
- 16 Ways
Technical Specifications
Small distribution board |
|
| Internal depth | 95 mm |
|---|---|
| Neutral terminal block | Yes |
| Signal passing door | No |
| Earthing terminal block | Yes |
| With lock | No |
| Transparent cover/door | No |
| With DIN-rail | Yes |
| Extension possible | No |
| EMC-version | Yes |
| With mounting plate | No |
| Width in number of modular spacings | 18 |
| Recess width | 464 mm |
| Recess height | 150 mm |
| Mounting method | Surface mounted |
|---|---|
| Recess depth | 264 mm |
| RAL number | 7004 |
| Number of rows | 1 |
| Depth | 264 mm |
| Height | 150 mm |
| Width | 464 mm |
| Colour | Grey |
| Housing material | Steel |
| Cover model | Closed |
| Degree of protection (IP rating) | IP3X |
| Type of covering | Door |
