Miniature circuit breaker (MCB) 10 A 3p characteristic: D
£110.23
Part Number: 2500332120 MPN: EMDH310 Product Type: Miniature Circuit Breakers
Description
Part Number: 2500332120 MPN: EMDH310 Product Type: Miniature Circuit Breakers
Product Details
EM miniature circuit-breaker, 3 pole, trip type: D, rated operational current In: 10 A, rated switching capacity according to IEC/EN 60947-2: 15 kA, rated switching capacity according to IEC/EN 60898-1: 10 kA, switchgear for residential and non-residential applications
- Breaking Capacity: 10/15kA
- Current Rating: 10A
- Height: 80mm
- Number of Poles: 3
- Range: Memshield 3
- Width: 54mm
- Capacity: 10/15kA
- Depth: 60mm
Technical Specifications
Miniature circuit breaker (MCB) |
|
| Width in number of modular spacings | 3 |
|---|---|
| Additional equipment possible | Yes |
| Flush-mounted installation | No |
| Explosion-proof | No |
| Concurrently switching N-neutral | No |
| Connectable conductor cross section multi-wired | 1 – 25 mm² |
| Ambient temperature during operating | -25 – 75 °C |
| Rated impulse-withstand voltage (Uimp) | 4 kV |
| Frequency | 50 – 60 Hz |
| Connectable conductor cross section solid-core | 1 – 25 mm² |
| Rated short-circuit breaking capacity Icn EN 60898 at 230 V | 10 kA |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 400 V | 15 kA |
| Rated short-circuit breaking capacity Icu IEC 60947-2 at 230 V | 15 kA |
| Tripping characteristic (type/curve) | D |
|---|---|
| Number of poles (total) | 3 |
| Rated short-circuit breaking capacity Icn EN 60898 at 400 V | 10 kA |
| Pollution degree | 2 |
| Over voltage category | 3 |
| Current limiting class | 3 |
| Number of protected poles | 3 |
| Rated insulation voltage Ui | 440 V |
| Rated voltage | 400 V |
| Rated current | 10 A |
| Voltage type | AC |
| Recess depth | 70.5 mm |
| Degree of protection (IP rating) | IP20 |
Additional information
| Weight | 0.0664 kg |
|---|---|
| Dimensions | 3.9 × 1.9 cm |
| Brands |
