Meets TP(a) requirements, suitable for all applications
£190.80
Part Number: 2501243410 MPN: JC080048 Product Type: LED
Description
Part Number: 2501243410 MPN: JC080048 Product Type: LED
Product Details
100 lumens per circuit Watt
- · 4000K colour temperature
- · IP20 protection
- · 100 lumens per circuit Watt
- · 4000K colour temperature
- · IP20 protection
- · Remote Plug and Play Emergency Pack – JCEM001 or JCEM001ST
- · 4 wire suspension kit and surface mount box available
Technical Specifications
Ceiling / wall luminaire |
|
| Dimming leading edge | No |
|---|---|
| Lamp included | Yes |
| Luminaire may be covered with thermally insulating material | No |
| Suitable for surface mounting | Yes |
| Suitable for recessed mounting | Yes |
| Fit for workplace acc. EN 12464-1 | Yes |
| Suitable for emergency lighting | Yes |
| Dimming touch and dim | No |
| Dimming Zigbee | No |
| Dimming sine wave reduction | No |
| Dimming RF | No |
| Dimming programmable | No |
| Dimming DSI | No |
| Dimming mains voltage modulation | No |
| Colour temperature | 4000 – – K |
| Control gear included | Yes |
| Suitable for suspended mounting | Yes |
| Dimming 0-10 V | No |
| Dimming LineSwitch | No |
| Dimming potentiometer (integrated) | No |
| Suitable for ceiling mounting | Yes |
| Dimming manufacturer’s proprietary system | No |
| Dimming with push-button | No |
| Dimming DMX | No |
| Dimming DALI | No |
| Dimming 1-10 V | No |
| Dimming trailing edge | No |
| Cover material | Plastic opal |
|---|---|
| Beam angle | Extreme wide beam >80° |
| Light distribution | Taperlock bush |
| Control gear | LED driver constant current |
| Voltage type | AC |
| Degree of protection (IP rating) | IP20 |
| Housing material | Steel |
| Housing colour | White |
| Energy efficiency class of light source according to EU regulation 2019/2015 | F |
| Connection type | Screwed terminal |
| Colour of light | White |
| Light sharing | Symmetric |
| Colour rendering index (CRI/Ra) | 80-89 |
| Light source type | LED non-replaceable |
| Light outlet | Direct |
| Protection class | II |
| Length | 595 mm |
| Luminaire efficacy | 100 lm/W |
| Number of poles | 2 |
| Rated luminous flux acc. IEC 62722-2-1 | 3000 lm |
| Height/depth | 32 mm |
| Power factor | 0.95 |
| Width | 595 mm |
| Maximum system power | 30 W |
| Rated ambient temperature acc. IEC62722-2-1 | 25 – – °C |
| Nominal voltage | 220 – 240 V |
