Harmony Single Contact Block for Head 1 NO Slow Break Gold Flashed

£12.74

Part Number: 2500069492     MPN: ZBE1016    Product Type: Command & Signalling

Categories: ,

Description

Part Number: 2500069492     MPN: ZBE1016    Product Type: Command & Signalling

Product Details

This Harmony ZB, single contact block for low power switching contacts uses screw-clamp terminals. It is compatible with Harmony XB4 and XB5 control and signaling units. This contact block, uses for low power switching contact, allows fast and easy replacement and configuration of specific control and signaling products. It is easily installed and replaced on XB4 and XB5 control and signalling units and connects to control circuits with simple screw-clamp connections. It protects operators from unexpected contact with live circuits thanks to its IP69K protection index. 1 million cycle high endurance under 6A load allows less maintenance and damage in your installation. It has clear color scheme for NO and NC contact block types. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.

  • This Harmony ZB, single contact block for low power switching contacts uses screw-clamp terminals.
  • It is compatible with Harmony XB4 and XB5 control and signaling units.
  • This contact block, uses for low power switching contact, allows fast and easy replacement and configuration of specific control and signaling products.
  • It is easily installed and replaced on XB4 and XB5 control and signalling units and connects to control circuits with simple screw-clamp connections.
  • It protects operators from unexpected contact with live circuits thanks to its IP69K protection index.
  • Tightening torque: 0.8-1.2Nm
  • Ambient temperature: -40 to 70°C
  • Vibration resistance 5gn
  • Shock resistance: 30-50gn
  • IP20 Degree of Protection

Technical Specifications

Auxiliary contact block
Type of electric connection Screw connection
Mounting method Front fastening
Model Clip-on
Lamp cap/base None
Rated operation current Ie at AC-15, 230 V 3 A



Number of fault-signal switches 0
Number of contacts as normally open contact 1
Number of contacts as normally closed contact 0
Number of contacts as change-over contact 0
