FP200G3C 4.0mm² White Fire Performance Soft Skin Standard Cable 3-Core

FP200G3C 4.0mm² White Fire Performance Soft Skin Standard Cable 3-Core

£15.48

Part Number: 2500043083     MPN: 20145483    Product Type: Fire Cables
Add to Wishlist
Add to Wishlist
Categories: , ,

Description

Part Number: 2500043083     MPN: 20145483    Product Type: Fire Cables

Product Details

This product is packaged as 100m Coil. Hence when ordering, a mutiple of 100 needs to be entered.

  • Cable Size: 4.0mm²
  • Colour: White
  • Length in metres: 100
  • No. of cores: 3
  • Product Packaging: Coil

Technical Specifications

Power cable < 1 kV, for fixed installations
Nominal voltage U 500 V
Low temperature resistant according to EN 60811-504+505+506 No
Oil resistant according to IEC 60811-404 No
Screen Yes
Drain wire Yes
Permitted cable outer temperature during assembling/handling 0 – 60 °C
Max. conductor temperature 70 °C
Outer diameter approx. 12.3 mm
Number of cores 3
Nominal voltage U0 300 V



Core insulation material Polyolefin
Nominal cross sectional area of conductor 4 mm²
Core identification Colour
Core colour Several
Conductor material Copper
Protective barrier None
Sheath colour Red
Conductor surface Bare
Sheath material Polyolefin
Conductor category Class 2 = stranded
